Pre Owned Nauticus Smart Tabs SX9510-60

This is a set of Pre-Owned Nauticus Smart Trim Tabs. They came off a 2010 Tahoe Q5i 19 foot fiberglass bowrider (runabout) designed for family recreation.

Nauticus SMART TABS SX fully automatic trim tabs combine the features of original SMART TABS with the corrosion- and maintenance-free benefits of durable composite construction. Enjoy improvements in acceleration, bow angle, ride and handling, top speed and fuel economy. Our top-selling SMART TABS SX system is an effective and affordable performance enhancing addition to many types of boats.

Applications:

• Outboard:
  • Boats 15′ – 17’+, 60 to 135 hp, 4 stroke motor
  • Boats 16′ – 18+’, 90 to 150 hp, 2 stroke motor
• I/O: Boats 16′ – 18’+, 4 or 6 cyl motor
• Dry weight up to 3,500 lbs
• RIBs, flats & bay, fish & ski, bow riders, deck, rescue, day cruisers

Features and Benefits:

• Fully automatic, continually active system eliminates the need for pilot interface
• Composite material provides superior strength and resilience in any rough water situation
• Plates absorb water and become more rugged over time
• Simple installation can be completed in an hour or less using common tools
• No zinc anodes required in saltwater applications

Specifications:

• Maintenance- and corrosion-free thermo-molded composite material
• Plates include five (5) actuator mounting positions to fine-tune the system
• Plates molded with two (2) mounting bosses
• 60 lb Actuators (GA5000-60X)

Dimensions:

• Trim Plate: 9.5″ W x 10″ L (TP9510 Series)
• Hinge: 8 3/4″ L x 2 1/8″ W (CH9510 Series)
